Growatt SPF 10KT HVM User Manual

29
Specifications
MODEL
SPF 4KT HVM
SPF 5KT HVM
SPF 6KT HVM
SPF 8KT HVM
SPF 10KT HVM
SPF 12KT HVM
Battery voltage
48VDC
48VDC
48VDC
48VDC
48VDC
48VDC
INVERTER OUTPUT
Rated Power
4KW
5KW
6KW
8KW
10KW
12KW
Surge Rating (20ms)
12KW
15KW
18KW
24KW
30KW
36KW
Waveform
Pure sine wave/ same as input (bypass mode)
Nominal Output Voltage
208V-220V-230V-240Vac(+/-10% RMS)
Output Frequency
50Hz/60Hz
（
+/-0.3 Hz
）
Inverter Efficiency(Peak)
>85%
Line Mode Efficiency
>95%
Power Factor
1.0
SOLAR CHARGER
Maximum PV Charge Current
80A
120A
DC Voltage
48V
Maximum PV Array Power
5000W
7000W
MPPT Operating Voltage(VDC)
60-145V
Max. PV Array Open Circuit
Voltage
150VDC
Maximum Efficiency
>98%
DC Input
Low DC Cut-Off Voltage (Only
Lead Acid)
Default @load<20%: 42.0V; @20%≤load<50%: 40.8V; @load≥50%: 38.4V
(Based on Program 21, default 42.0V ,40Vdc~48Vdc settable)
Low DC Warning Voltage (Only
Lead Acid)
Low DC Cut-Off Voltage +2Vdc
Low DC Warning Return
Voltage (Only Lead Acid)
>48V
Low DC Warning SOC (Only Li)
<Low DC Cut-off SOC +5%
Low DC Warning Return SOC
(Only Li
）
>Low DC Cut-off SOC +15%
Low DC Cut-off SOC (Only Li)
Default 20%, 5%~50% Settable
Cold Start SOC (Only Li)
>Low DC Cut-off SOC+10%
High DC Recovery Voltage
58VDC
High DC Cut-Off Voltage
AGM:60V, FLD:62V, USE or Li Mode: C.V. Voltage + 4.0V
AC INPUT
Voltage
230VAC
Selectable Voltage Range
154~272VAC(for appliances ), 184~272VAC(for UPS)
Frequency Range
50Hz/60Hz (Auto sensing)
Maximum Charge Current
40A
50A
60A
70A
80A
100A
BYPASS & PROTECTION
（
Grid & Generator
）
Typical Transfer Time
10ms
Overload Protection (SMPS
Load)
Circuit breaker
