Grundfos 32-120 F User Manual

English (GB)
14
Technical data
Ambient temperature
0-40 °C.
Ambient temperature during transport: -40 to
+70 °C.
Liquid temperature
Continuously: -10 to +110 °C.
Stainless steel pumps in domestic hot-water
systems:
In domestic hot-water systems, we
recommend that you keep the liquid
temperature below 65 °C to eliminate the
risk of lime precipitation.
Ambient temperatures below 0 °C
require the following conditions:
• The media temperature is 5 °C.
• The media contains glycol.
• The pump runs continuously and
does not stop.
• For twin-head pumps cascade
operation every 24 hours is
mandatory.

Grundfos 32-120 F Specifications

General

Model	Grundfos 32-120 F
Category	Water Pump
Pump Type	Centrifugal Pump
Frequency	50 Hz
Max Pressure	16 bar
Connection Type	Flanged
Pump Housing Material	Cast Iron
Liquid Temperature Range	-25 .. 120 °C
Nominal Diameter	32 mm
Shaft Seal	Mechanical Seal
