Page #8 background imageLoading...
Page #8 background image
English (GB)
8
Electrical installation
Fit and tighten the screw holding the
clamp to 8 Nm ± 1 Nm. Do not apply
more torque than specified even
though water is dripping from the
clamp. The condensed water is most
likely coming from the drain hole under
the clamp.
Check the position of the clamp before
you tighten it. Incorrect position of the
clamp will cause leakage from the
pump and damage the hydraulic parts
in the pump head.
WARNING
Electric shock
Death or serious personal injury
- Lock the main switch in position 0.
Type and requirements as specified
in EN 60204-1, 5.3.2.
8Nm!

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Grundfos 32-120 F and is the answer not in the manual?

Grundfos 32-120 F Specifications

General IconGeneral
ModelGrundfos 32-120 F
CategoryWater Pump
Pump TypeCentrifugal Pump
Frequency50 Hz
Max Pressure16 bar
Connection TypeFlanged
Pump Housing MaterialCast Iron
Liquid Temperature Range-25 .. 120 °C
Nominal Diameter32 mm
Shaft SealMechanical Seal
