Grundfos 32-120 F User Manual

English (GB)
6
Type key
CodeExample (D) 40 -80 (F) (N) 220
Type range
MAGNA1
D
Single-head pump
Twin-head pump
Nominal diameter
(DN) of inlet and
outlet ports [mm]
Maximum head [dm]
F
Pipe connection
Threaded
Flange
N
Pump housing material
Cast iron
Stainless steel
Port-to-port length [mm]

Grundfos 32-120 F Specifications

General

Model	Grundfos 32-120 F
Category	Water Pump
Pump Type	Centrifugal Pump
Frequency	50 Hz
Max Pressure	16 bar
Connection Type	Flanged
Pump Housing Material	Cast Iron
Liquid Temperature Range	-25 .. 120 °C
Nominal Diameter	32 mm
Shaft Seal	Mechanical Seal
