Grundfos 50 F Series User Manual

English (GB)
8
Electrical installation
Fit and tighten the screw holding the
clamp to 8 Nm ± 1 Nm. Do not apply
more torque than specified even
though water is dripping from the
clamp. The condensed water is most
likely coming from the drain hole under
the clamp.
Check the position of the clamp before
you tighten it. Incorrect position of the
clamp will cause leakage from the
pump and damage the hydraulic parts
in the pump head.
WARNING
Electric shock
Death or serious personal injury
- Lock the main switch in position 0.
Type and requirements as specified
in EN 60204-1, 5.3.2.
8Nm!

Grundfos 50 F Series Specifications

General

Protection class	IP55
Insulation class	F
Type	Centrifugal pump
Pump housing	Cast iron
Impeller	stainless steel
Frequency	50 Hz / 60 Hz
Connection type	Flange
Speed	2900 rpm
Liquid temperature	-10°C to +120°C
Voltage	230V or 400V
