5. Installation requirements
5.1 Location
TM076422
Location of the pump and accessories
Pos. Description
1 Water supply
2 Cold-water supply
3 Hot-water supply
The system is intended for indoor use only in
areas protected from droplets and splashes.
Maximum ambient temperature is 104 °F (40 °C).
Push-button HWR-D
Do not install the push-button HWR-D in a shower
or under the tap or faucet where it could be
exposed to water. Mount it at a suitable height out
of reach of small children and pets.
Repeater
This repeater is only for use with the ALPHA
15-55 HWR-D system and is intended for indoor
installation only in areas safe from droplets and
splashes.
For optimum use, place the repeater between the
ALPHA 15-55 HWR-D pump and the push-button
located furthest away from the pump.
5.2 Tools
You will need the following tools to install the
system:
• Hexagon key 4 mm
• Pipe wrench
8
English (US)
