Grundfos CIM 500

Object Description
IP Address
Configuration of the static IP address if a DHCP server is not used. EtherNet/IP is not
allowed to share the IP address with the CIM 500 webserver
.
Subnet Mask Configuration of the subnet mask if a DHCP server is not used.
Gateway Configuration of the gateway address if a DHCP server is not used.
Use DHCP
The CIM 500 module can be configured to automatically obtain its EtherNet/IP network
settings from a DHCP server, if available on the network. Default: No use of DHCP.
Communication
Watchdog
For enabling a 5 seconds communication watchdog timer. Only active for pump or
booster products.
Unchecked: Watchdog is disabled (default).
Checked: Watchdog is enabled, time-out is 5 seconds.
Watchdog action: The pump or the booster is set to local mode.
Grundfos product
simulation
The module can be put in product simulation mode to generate realistic simulated values
of all the EtherNet/IP input data. It is thus possible to connect an EtherNet/IP master to a
module fitted in a CIU or an E-box without installing this device in a real industrial process
system. In an office environment, it can then be verified that communication works, and
data is received and handled correctly by the EtherNet/IP master application program (for
example PLC program) before installing the device.
To enable product simulation, select a product type from the dropdown list.
To terminate product simulation, select "No Simulation".
290
Appendix A
