Grundfos COMFORT 10-16 Temperature control User Manual

To watch the COMFORT Digital Timer instruction video, scan the QR code
below.
QR_COMFORT-DT_INSTRUCTIONVIDEO
http://v2.t2g.me/?q=fc0652a6
5.3.2 Setting the pump to continuous 100 % mode
The pump is factory set to run at continuous 100 % mode.
1. When the pump is powered on the 100 % LED is lit.
5.3.3 Setting the actual time
1. Press the Arrow button to start the process. The gear wheel LED lights up.
2. Move the actual timer LED by pressing the Change button until it indicates
the actual time.
One LED equals a time interval of 30 minutes.
3. Confirm by pressing OK.
5.3.4 Setting the timer
Once the actual time has been set the pump's timer LEDs become lit according
to the default timer settings. They are as follows:
• 6-9 AM (06:00-09:00)
• 11 AM - 1 PM (11:00-13:00)
• 4-9 PM (16:00-21:00)
If you want to keep the default settings press the Arrow button to confirm.
If you want to customize the timer, do as follows:
1. Press the Arrow button.
2. Move the timer LED by pressing the Change button.
17
English (US)

Grundfos COMFORT 10-16 Temperature control Specifications

General

System pressure	10 bar
Pump Type	Circulator pump
Voltage	230 V
Frequency	50 Hz
Max. Liquid Temperature	95 °C
Liquid temperature range	2°C to 95°C
Approvals	CE
