Grundfos COMFORT 10-16 Temperature control User Manual

3. Select or deselect a time period by pressing OK.
One LED equals a time interval of 30 minutes.
4. Press the Arrow button to confirm the settings.
5.3.5 Resetting to factory setting
When resetting the timer, all saved time periods will be lost.
1. Press and hold the Arrow button for 5 seconds.
All LEDs light up, after which the actual time LED blinks and the 100 % LED is
lit.
18
English (US)

Grundfos COMFORT 10-16 Temperature control Specifications

General

System pressure	10 bar
Pump Type	Circulator pump
Voltage	230 V
Frequency	50 Hz
Max. Liquid Temperature	95 °C
Liquid temperature range	2°C to 95°C
Approvals	CE
