Grundfos CRE Series Product Guide

Technical data
44
All dimensions in inches unless otherwise noted.
*Oval flanged pump B1 and B1+B2 dimension is equal to ANSI flanged pumps and weight is approximately 7 lbs. less.
• Available.
TM03 1458 2205
3 15/16"
10 1/8"
4 x ø9/16"
8 1/2"
9 3/4"
5 1/8"
7 7/8"
1 1/16"
M12x80
3 1/2"
B1
G 1/2 PLUG
WITH 1/4"TAP
FOR GAUGE/
SENSOR
PRIMING
PORT (G 1/2)
DISCHARGE
SUCTION AND
2" NPT
PLUG (G 1/2)
DRAIN
B2
D2
D1
TM03 1459 2205
3/4 x 7/8"
ø5"
11 7/8"
ø6 1/2"
ø4 3/4"
ø2 9/16"
1 1/16"
7 7/8"
5 1/8"
9 3/4"
8 1/2"
4 x ø9/16"
3 1/2"
B1
G 1/2 PLUG
WITH 1/4"TAP
FOR GAUGE/
SENSOR
PRIMING
PORT (G 1/2)
PLUG (G 1/2)
DRAIN
B2
D2
D1
2" ANSI 300 lb. R.F.
Pump
type
P2
[hp]
Ph. Oval*
ANSI dimensions [inch]
Ship
Wt.
[lbs.]
ANSI dimensions [inch]
Ship
Wt.
[lbs.]B1
TEFC ODP MLE
D1 D2 B1+B2 D1 D2 B1+B2 D1 D2 B1+B2
CRI(E) 10-1 1
1
•
15.20 7.19 5.73 26.39 - - - 106 5.55 5.51 24.18 97
3
•
15.20 5.55 4.57 22.64 - - - 97 7.01 6.57 28.00 119
CRI(E) 10-2 1 1/2
1
•
15.20 7.19 5.73 26.88 - - - 121 - - - -
3
•
15.20 5.55 4.57 23.82 - - - 99 7.01 6.57 28.00 119
CRI 10-3 3
1
•
17.13 8.60 6.87 31.78 - - - 174 - - - -
3
•
17.13 7.01 4.33 30.36 - - - 147 - - - -
CRI(E) 10-4 3
1
•
18.31 8.60 6.87 32.96 - - - 176 - - - -
3
•
18.31 7.01 4.33 31.54 - - - 147 7.01 6.57 31.62 157
CRI 10-5 5
1
•
19.49 10.62 7.46 35.01 - - - 203 - - - -
3
•
19.49 8.66 5.28 35.00 - - - 199 - - - -
CRI(E) 10-6 5
1
•
20.67 10.62 7.46 36.19 - - - 205 - - - -
3
•
20.67 8.66 5.28 36.18 - - - 201 8.66 7.40 36.18 194
CRI 10-7 7 1/2
1
•
22.17 10.22 7.62 37.70 - - - 225 - - - -
3
•
22.17 8.66 5.28 37.68 - - - 212 - - - -
CRI(E) 10-8 7 1/2
1
•
23.35 10.22 7.62 38.88 - - - 227 - - - -
3
•
23.35 8.66 5.28 38.86 - - - 214 8.66 7.40 38.86 229
CRI 10-9 7 1/2
1
•
24.53 10.22 7.62 40.06 - - - 229 - - - -
3
•
24.53 8.66 5.28 40.04 - - - 216 - - - -
CRI(E) 10-10 7 1/2
1
•
25.71 10.22 7.62 41.24 - - - 232 - - - -
3
•
25.71 8.66 5.28 41.22 - - - 218 8.66 7.40 41.22 234
CRI(E) 10-12 10
1 - 28.07 10.23 10.30 44.14 - - - 346 - - - -
3 - 28.07 8.66 5.28 43.58 - - - 225 10.24 8.39 42.99 243
CRI(E) 10-14 15 3 - 32.95 10.22 8.67 49.53 10.62 7.33 49.26 432 13.39 12.13 51.73 497
CRI 10-16 15 3 - 35.31 10.22 8.67 51.89 10.62 7.33 51.62 442 - - - -
CRI(E) 10-17 15 3 - 37.68 10.22 8.67 54.26 10.62 7.33 53.99 447 13.39 12.13 56.46 513
CRI(E) 10

Grundfos CRE Series Specifications

General

Motor Type	Asynchronous
Enclosure Class	IP55
Insulation Class	F
Series	CRE
Protection Class	IP55
Material	Stainless Steel
Applications	Water Supply, Pressure Boosting, Irrigation
Pumped liquid	Clean liquids
Approvals	CE
Voltage	380-415V
Connection Size	DN 32 to DN 100
Efficiency	IE3 Premium Efficiency
Power Supply	3-phase
Liquid Temperature Range	-10°C to +120°C
Temperature Range	-10°C to +120°C
