English (GB) Installation and operating instructions
Original installation and operating instructions.
CONTENTS
Page
1. Symbols used in this document
2. Operating pumps with VFD
This manual describes additional conditions or special
considerations affecting the operation of pumps with variable
frequency drive (VFD).
3. Link to Nord documents
4. Technical data
For technical data and ambient and operating conditions refer to
the installation and operating instructions of the dosing pump.
For electrical data such as current consumption see the
nameplates of the motor and the VFD.
Dimensions of DMX and DMH pumps with VFD
For dimensions of pumps with VFD see Appendix on page 64.
For all other dimensions see the installation and operating
instructions of the dosing pump.
5. Identification and variants
DMX and DMH pumps with PTC motors and integrated VFD are
available in different variants, which are shown on the nameplate
of the pump as follows:
5.1 Type key
Example of type key:
DMX 95-8 B-PP/E/T-X-E1AAXFA
1. Symbols used in this document
4
2. Operating pumps with VFD
4
3. Link to Nord documents
4
4. Technical data
4
5. Identification and variants
4
5.1 Type key
4
6. Electrical connection
5
6.1 Power supply
5
7. VFD specification
5
7.1 VFD variants used with DMX and DMH pumps
5
7.2 Operation modes
5
7.3 Special parameter settings for DMX/DMH
6
Warning
Prior to installation, read these installation and
operating instructions. Installation and operation
must comply with local regulations and accepted
codes of good practice.
Warning
In addition to these instructions, observe all
installation and operating instructions supplied
with the pump.
The installation and operating instructions for
the pump and the supplier manual "BU 0180" for
the VFD are available on the CDs delivered with
the product and on www.nord.com /
www.grundfos.com.
Warning
If these safety instructions are not observed,
it may result in personal injury.
If these safety instructions are not observed, it
may result in malfunction or damage to the
equipment.
Notes or instructions that make the job easier
and ensure safe operation.
This manual is only valid together with the
installation and operating instructions for the
pump and the supplier manual "BU 0180" for the
VFD. All documents should be used.
VFD used with Grundfos DMX and DMH pumps
are available with selected variants and with
special parameter settings.
Observe deviations from the supplier range of
VFD, see sections 7.1 VFD variants used with
DMX and DMH pumps and 7.3 Special parameter
settings for DMX/DMH.
Find more information in the suppliers manuals
"BU 0180" and additional manuals in various
languages on https://www.nord.com.
The values stated on the nameplates and in the
installation and operating instructions of the
dosing pump must be observed.
Code Example: DMX ... F A
DMX
DMH
Pump type
DMX
DMH
...
Variant
See pump type key
F
G
H
K
Certificate included
No
For motor
For pump
For motor and pump
A
B
C
D
E
VFD variant
Standard VFD
With I/O extension board
With internal Profibus
With external Profibus
With external Profinet
