Grundfos Geo-Flo Universal Pump Controller - Appendix E: Controller Mounting Template

  
Appendix E: Controller Mounng Template
6"
SUGGESTED MOUNTING
HOLE LOCATIONS
SUGGESTED MOUNTING
HOLE LOCATIONS
This document must be printed full-scale to properly mark the mounng-hole locaons. The
Page Scaling in the Print dialog box in Adobe Acrobat must be set to None. The 6-inch line can
be used as reference to ensure the document has been printed full-scale.
