Grundfos Geo-Flo Universal Pump Controller User Manual

24  Rev. 05JUL2016
Appendix F1: Pressurized Variable Speed Flow Center Submials
FLV Series Variable Speed Pressurized Flow Center, Single Pump
SD 1298 rev. 21SEP2013
Submial Data
Technical Data
Electrical and Power Data
Pump Performance Curves
Mounng
GEO-FLO PRODUCTS CORPORATION
905 Williams Park Drive
Bedford, IN 47421
Phone: 812-275-8513 Fax: 812-275-8523
www.geo-o.com
Curves are manufacturer‘s reported averages using water at 68°F [20°F].
Project Name:
Contractor:
Engineer:
Order Number:
Addional Informaon:
Approved Anfreeze
Propylene Glycol
Ethanol
Methanol
Max. Fluid Temperature: 140°F [60°C]
Min. Fluid Temperature: 20°F [-7°C]
Max. Oper. Press.: 145 psi [1 Mpa]
Min. Operang Press.: 1.3 psi [9 kPa]
Max. Ambient Air Temp: 104°F [40°C]
Flow Center is designed for
indoor installaon only.
Flow Center must be installed with
the pump’s motor sha horizontal.
Do not install ow center with the
pump’s motor sha vercal.
The terminal box should be located in
one of the following orientaons:
Grundfos Magna GEO 32-140 variable speed
High Impact Polystyrene plasc
CFC-free, polyurethane foam
1” Full-port, 3-Way, 4-Posion ushing and isolaon/service valve,
Brass body and spool, NBR seals, stainless steel retaining ring.
Motor: 208-230V, 50/60 Hz, single phase, 2-pole, ETL
C/US
approved (meets UL and CSA require-
ments), electronically protected, insulaon class F, 0.09 to 1.7 Amps (at 230V)
Circulator:
Cabinet:
Insulaon:
Valves:
0 10 20 30 40
Flow (U.S. GPM) [l/s]
Grundfos Magna GEO 32-140 Power
0
50
100
150
200
250
Power (Was)
[0.63 1.26 1.89 2.52]
Flow (U.S. GPM) [l/s]
Grundfos Magna GEO 32-140 Performance Curves (Single Pump)
Head (Feet) [kPa]
[0.32 0.63 0.95 1.26 1.58 1.89 2.21 2.52 2.84 3.15]
Pump operates in
between these curves
to maintain flow rate
or temperature diff.
0
5
10
15
20
25
30
35
40
45
50
[134.3]
[14.9]
[29.8]
[44.8]
[59.7]
[74.6]
[89.5]
[104.5]
[119.4]
[149.2]
0 5 10 15 20 25 30 35 40 45 50
NOTES: The Magna GEO (vari-
able speed) pump adjusts speed
(when used with controller) to
maintain ow rate or tem-
perature dierence. For Was
based upon a specic ow rate
and pressure drop, go to www.
geo-o.com, and use the pump
sizing calculator.
