Grundfos Geo-Flo Universal Pump Controller User Manual

28  Rev. 05JUL2016
Appendix F2: Non-Pressurized Variable Speed Flow Center Submials
.
Submial Data
non-pressurized ow center, variable speed pump
Project Name:
Contractor:
Engineer:
Order Number:
Addional Informaon:
Technical Data
Electrical and Power Data Approved Anfreeze
Mounng
Pump Performance Curves
Circulator:
Cabinet:
Tank:
Insulaon:
Valves:
Grundfos Magna GEO 32-140 (variable speed--requires controller)
Powder coated galvanized steel
Polyvinyl chloride (PVC)
CFC-free polyurethane foam
1”, 3-way, 4-posion ushing and isolaon/service valve, composite
valve body and spool, NBR seals, stainless steel retaining ring
Max. uid temp.: 140°F [60°C]
Min. uid temp.: 14°F [-10°C]
Max. operang press.: 13 psig [89.6 kPa]
Max. ambient air temp.: 104°F [40°C]
Max. ambient relave humidity: 80%
Propylene Glycol
Methanol
Ethanol
Curves are manufacturer’s reported averages using water at 68°F [20°C].
Flow center is
designed for indoor
installaon only.
Flow center must
be installed in an
upright posion as
shown to the right.
The pump terminal
box should be
located in one of the
following orienta-
ons:
Motor: 208-230V, 50/60 Hz, single phase, 2-pole, ETL
C/US
approved (meets UL and CSA
requirements), electronically protected, insulaon class F, 0.09 to 1.7 Amps (at 230V)
GEO-FLO PRODUCTS CORPORATION
905 Williams Park Drive
Bedford, IN 47421 U.S.A.
PH: 812-275-8513; FAX: 812-275-8523
www.geo-o.com
SD 1275 rev. 02JAN2013
Flow (U.S. GPM) [l/s]
Grundfos Magna GEO 32-140 Performance Curves (Single Pump)
Head (Feet) [kPa]
[0.32 0.63 0.95 1.26 1.58 1.89 2.21 2.52 2.84 3.15]
Pump operates in
between these curves
to maintain flow rate
or temperature diff.
0
5
10
15
20
25
30
35
40
45
50
[134.3]
[14.9]
[29.8]
[44.8]
[59.7]
[74.6]
[89.5]
[104.5]
[119.4]
[149.2]
0 5 10 15 20 25 30 35 40 45 50
0 10 20 30 40
Flow (U.S. GPM) [l/s]
Grundfos Magna GEO 32-140 Power
0
50
100
150
200
250
Power (Was)
[0.63 1.26 1.89 2.52]
NOTES: The Magna GEO
(variable speed) pump
adjusts speed (when used
with controller) to maintain
ow rate or temperature
dierence. For Was based
upon a specic ow rate and
pressure drop, go to
www.geo-o.com, and use
the pump sizing calculator.
NP
1
NP
2
NP
V
NP
V2
NP Series
