Technical data
SQFlex
SQF pump
Supply to pump
1 x 90 - 240 V –10%/+6%, 50/60 Hz.
30 - 300 VDC.
Run-up time Depending on power source.
Start/stop No limitation to the number of starts/stops per hour.
Enclosure class IP 68.
Motor protection
Built into the pump.
Protection against:
- Dry running by means of a water level electrode.
- Overvoltage and undervoltage.
- Overload.
- Overtemperature.
Conductivity ≥ 70 µs/cm (micro siemens).
Sound pressure level The sound pressure level is lower than the limiting values stated in the EEC Machinery Directive.
Radio noise
SQF comply with EMC Directive 89/336/EEC.
Approved according to EN 50081-1 and 50082-2.
Reset function SQF can be reset via CU 200 or by disconnecting the power from the power supply in 1 minute.
Power factor PF = 1.
Operation via generator
Voltage: 115 VAC, –10%/+6%.
The generator output must be a minimum of 1000 Watts.
Earth leakage circuit breaker
If the pump is connected to an electrical installation where an earth-leakage circuit breaker
(ELCB) is used as an additional protection, this circuit breaker must trip out when earth fault
currents with DC content (pulsating DC) occur.
Borehole diameter
3 SQF-2, 6 SQF-2, 11 SQF-2: Minimum: 3 inch.
25 SQF-3, 25 SQF-6, 40 SQF-3, 75 SQF-3: Minimum: 4 inch.
Installation depth
Min.: The pump must be totally submerged in the pumped liquid.
Max.: 500 ft below the static water table (220 psi).
Suction strainer
Holes of the suction strainer:
3 SQF-2, 6 SQF-2, 11 SQF-2: 0.090 inch.
25 SQF-3, 25 SQF-6: 0.10 inch.
40 SQF-3, 75 SQF-3: 0.16 inch x 0.79 inch.
Pumped liquids
pH 5 to 9.
Sand content up to 50 ppm.
Marking CE
IO 100 switch box
Voltage
Max. 225 VDC, 7 A.
Max. 265 VAC, 7 A.
Enclosure class IP 55 / NEMA 3R.
Ambient temperature In operation: –22°F to +122°F; during storage: –22°F to +140°F.
Marking CE
IO 101 switch box
Voltage
115 VAC –15%/+10%, 50/60 Hz (internal relay).
Max. 225 VDC, 7 A
Max. 265 VAC, 7 A
Enclosure class IP 55 / NEMA 3R.
Ambient temperature In operation: –22°F to +122°F; during storage: –22°FC to +140°F.
Marking CE
IO 102 breaker box
Voltage
Max. 225 VDC, 7 A.
Max. 265 VAC, 7 A.
Enclosure class IP 55 / NEMA 3R.
Ambient temperature In operation: –22°C to +122°F; during storage: –22°C to +140°F.
Marking CE
