30
Technical data
SQFlex
CU 200 control unit
Voltage
30 - 300 VDC
90 - 240 VAC –10%/+6%, 50/60, PE.
Power consumption 5 W.
Current consumption Max. 130 mA.
Enclosure class IP 55 / NEMA 3R.
Ambient temperature In operation: –22°C to +140°F; during storage: –22°C to +140°F.
Relative air humidity 95%.
Pump cable
Max. length between CU 200 and pump: 660 feet.
Max. length between CU 200 and level switch: 1640 feet.
Back-up fuse Max.: 10 A.
Radio noise
The CU 200 complies with EMC Directive 89/336/EEC.
Approved according to standards EN 55 014 and 55 014-2.
Marking CE.
Weight 4.5 lb
