10. Technical data
10.1 Operating conditions
System pressure Max. 87 psi (6 bar / 0.60 MPa)
Suction lift
Max. 26.25 ft (8 m), including inlet-pipe
pressure loss at a liquid temperature
of 68 °F (20 °C)
Liquid temperature
Max.
104 °F (40 °C) (S1 mode*) /
140 °F (60 °C) (S3 mode**)
Ambient
temperature
Max.
104 °F (40 °C) (S1 mode*) /
131 °F (55 °C) (S3 mode**)
Relative humidity Max. 98 %
Enclosure class IP44
Insulation class F
Supply voltage
1 x 115 V, 60 Hz
1 x 230 V, 60 Hz
Start/stop frequency Max. 20 per hour
Sound pressure
level
Max. sound pressure level of the pump:
JP 13 03 137: 68 [dB(A)]
JP 18 05 154: 70 [dB(A)]
JP 18 07 177: 74 [dB(A)]
JP 22 10 157: 81 [dB(A)]
* S1 mode: The pump runs continuous operation.
** S3 mode: The pump's overheating protection ensures the pump runs intermittent
operation when the air temperature is too high to cool the motor efficiently.
Related information
4.1.3 Ambient temperature during operation
4.2.2.1 Maximum system pressure
10.2 Head and flow rate
Max. head
JP PS 13 03 137: 137 ft (42 m)
JP PS 18 05 154: 154 ft (47 m)
JP PS 18 07 177: 177 ft (54 m)
JP PS 22 10 157: 157 ft (48 m)
Max. flow rate
JP PS 13 03 137: 13.2 gpm (3 m
3
/h)
JP PS 18 05 154: 17.6 gpm (4 m
3
/h)
JP PS 18 07 177: 17.6 gpm (4 m
3
/h)
JP PS 22 10 157: 22.0 gpm (5 m
3
/h)
10.3 Inlet pressure
Model
Max. inlet pressure
JP 13 03 137 21.75 psi (1.5 bar / 0.15 MPa)
JP 18 05 154 14.50 psi (1.0 bar / 0.10 MPa)
JP 18 07 177 7.25 psi (0.5 bar / 0.05 MPa)
JP 22 10 157 14.50 psi (1.0 bar / 0.10 MPa)
Related information
4.2.2.1 Maximum system pressure
10.4 Miscellaneous data
Cut-in pressure
Preset cut-in pressure (start pressure):
JP PS: 30-50 psi
Min./max. storage
temperature
-4/+158 °F (-20/+70 °C)
11. Disposing of the product
1. Use the public or private waste collection service.
2. If this is not possible, contact the nearest Grundfos company or
service workshop. See also end-of-life information at
www.grundfos.com/product-recycling.
3. Consider recycling scrap metal to reduce waste and to help to
limit new mining.
21
English (US)
