Pos. Code Explanation
7 F1
Pipe connection
F1: 10 bar, DIN PN 10
F2: 16 bar, DIN PN 16
F3: 25 bar, DIN PN 25
XX: Special flange
G1: 175PSI(12 bar), ANSI125LB/150LB
G2: 250PSI(17.2 bar), ANSI250LB/300LB
G3: 400PSI(27.6 bar), ANSI250LB/300LB
8 D
Code for shaft and sleeve materials
D: SS420 and no sleeve
E: SS304 and no sleeve
J: SS316 and no sleeve
L: Duplex stainless steel and no sleeve
X: Special
B: SS420 and bronze
A: SS420 and SS304
C: SS420 and SS316
K: Duplex stainless steel and duplex
stainless steel
Q: Alloy steel and no sleeve
M: Alloy steel and bronze
N: Alloy steel and SS304
