13
More than one product?
The R100 can only communicate with one product at a time. If the R100
comes into contact with more than one product, it is necessary to select a
product.
Possible solutions:
• Move the R100 closer to the product in question and press .
• Hide the line of sight to the product next to the desired product, for exam-
ple with your hand, and press .
If the product has already been given a unique number, you can select the
number of the product you want to communicate with.
4. Menu structure
Each product has a specific menu structure.
The functions in the GENERAL menu are common to all products. The main
functions are described on the next pages.
The displays relating to the individual product are described in detail in
the installation and operating instructions for the product in question.
Setting field
The current/last transferred value will appear as light-coloured text on a dark
background.
When values are changed, the text will be dark-coloured on a light back-
ground.
When has been pressed and the new data have been transferred to
the product, the text will again be light-coloured.
Continuous display of status values
When is pressed continuously in a display under OPERATION or
STATUS, the displayed value is being updated continuously.
