6.8 Identification
6.8.1 Nameplate
Fig. 10 Example of nameplate
7. Maintaining the product
Clean the strainer every fall with a brush and a water
jet when needed. In normal operation, the pump
does not require any specific maintenance.
TM07 1530 1618
Pos. Description
1 Product type
2 Frequency [Hz]
3 Production code, year and week
4
50 Hz, P1: Power input [W]
60 Hz, P2: Motor output [HP]
5 Serial number
6 Full-load current [A]
7 Maximum installation depth [m]
8 Maximum liquid temperature [°C]
9 Enclosure class
10 Manufacturer
11 Motor insulation class
12 Maximum head [m]
13 Country of origin
14 Approval marks
15 Waste electrical and electronic equipment
16 Maximum flow rate [l/min]
17 Supply voltage [V]
18 Product number
Type
Model
1x220
Q
max
Made in Italy by Grundfos
SB HF 5-50 A
9xxxxxxx
V~ 60Hz P
2
130 l/m Hmax
P10 3.1810 SN100001
1.5 HP
U
I
1/1 7.6 A
50m T
max 40°C 15m
IP68Insulation Class F
DK - 8850 Bjerringbro, Denmark
12
14 13 12 11 10
34 5
18
17
16
15
6
7
8
9
DANGER
Electric shock
Death or serious personal injury
- If the power supply cable is damaged, it
must be replaced by the manufacturer,
his service agent or similarly qualified
persons in order to avoid hazard.
