7. Technical data
Supply voltage
1 × 220-240 V - 10 %/+ 6
%, 50 Hz
Power consumption Maximum 640 W
Power factor Cos φ 0.66 / 0.90
Speed
2800 min
-1
Rated current 3.1 A
Insulation class F
Noise level < 70 dB(A) to 12050-2
Flow rate Maximum 204 l/min
Supply cable
1.2 m, 0.75 mm
2
(H05VV-F-3G)
Net weight 6.6 kg.
Start and stop levels
Start level 1: 65 mm
above floor level
Start level 2: 115 mm
above floor level
Stop level: 35 mm above
floor level
Liquid temperature
Maximum 75 °C
continuously (90 °C for
30 minutes)
Brine from a water
softener: maximum 20 °C
Brine Maximum 15 % of salt
Ambient temperature 5-35 °C
Duty
S3 - 50 % - 1 minute (30
seconds on; 30 seconds
off)
System pressure
Maximum pump head: 8
m
Maximum system head:
6 m
The system pressure must not exceed 6 m
head to guarantee a sufficient drain of the
connected sanitary appliances.
Approvals and markings
8. Disposing of the product
This product or parts of it must be disposed of in an
environmentally sound way.
1. Use the public or private waste collection service.
2. If this is not possible, contact the nearest
Grundfos company or service workshop.
The crossed-out wheelie bin
symbol on a product means
that it must be disposed of
separately from household
waste. When a product
marked with this symbol
reaches its end of life, take it
to a collection point
designated by the local waste
disposal authorities. The
separate collection and
recycling of such products will
help protect the environment
and human health.
See also end-of-life information at
www.grundfos.com/product-recycling.
9. Document quality feedback
To provide feedback about this document, scan the
QR code using your phone’s camera or a QR code
app.
FEEDBACK_97771617
Click here to submit your feedback
11
English (GB)
