10.6 Electrical data
10.6.1 Grundfos submersible motors, 60 Hz
Grundfos submersible motors, 60 Hz
Hp Ph
Volt
[V]
SF
Circuit breaker or fuses Amperage Full load
Max. thrust
[lbs]
Std. Delay
Start
[A]
Max.
[A]
Eff.
[%]
Power factor
4-inch, single-phase, 2-wire motors (control box not required)
0.5 1 115 1.60 35 15 55.0 12.0 62 76 900
0.5 1 230 1.60 15 7 34.5 6.0 62 76 900
0.75 1 230 1.50 20 9 40.5 8.4 62 75 900
1 1 230 1.40 25 12 48.4 9.8 63 82 900
1.5 1 230 1.30 35 15 62.0 13.1 64 85 900
4-inch, single-phase, 3-wire motors
0.5 1 115 1.60 35 15 42.5 12.0 61 76 900
0.5 1 230 1.60 15 7 21.5 6.0 62 76 900
0.75 1 230 1.50 20 9 31.4 8.4 62 75 900
1 1 230 1.40 25 12 37.0 9.8 63 82 900
1.5 1 230 1.30 35 15 45.9 11.6 69 89 900
2 1 230 1.25 35 20 57.0 13.2 72 86 1500
3 1 230 1.15 45 30 77.0 17.0 74 93 1500
5 1 230 1.15 70 45 110.0 27.5 77 92 1500
4-inch, three-phase, 3-wire motors
1.5 3 230 1.30 15 8 40.3 7.3 75 72 900
1.5 3 460 1.30 10 4 20.1 3.7 75 72 900
1.5 3 575 1.30 10 4 16.1 2.9 75 72 900
2 3 230 1.25 20 10 48 8.7 76 75 900
2 3 460 1.25 10 5 24 4.4 76 75 900
2 3 575 1.25 10 4 19.2 3.5 76 75 900
3 3 230 1.15 30 15 56 12.2 77 75 1500
3 3 460 1.15 15 7 28 6.1 77 75 1500
3 3 575 1.15 15 6 22 4.8 77 75 1500
5 3 230 1.15 40 25 108 19.8 80 82 1500
5 3 460 1.15 20 12 54 9.9 80 82 1500
5 3 575 1.15 15 9 54 7.9 80 82 1500
7.5 3 230 1.15 60 30 130 25.0 81 82 1500
7.5 3 460 1.15 35 15 67 13.2 81 82 1500
7.5 3 575 1.15 30 15 67 10.6 81 82 1500
10 3 460 1.15 50 30 90 18 81 80 1500
Single-phase motors (thermally protected): Use with
approved motor control that matches the motor input in full
load amperes.
Three-phase motors: Use with approved motor control
that matches the motor input in full load amperes with
overload element(s) selected or adjusted according to
control instructions.
39
English (US)
