Grundfos SP Series User Manual

Grundfos submersible permanent-magnet motors, 60 Hz
Hp Ph
Volt
[V]
SF
Amperage Full load
Max. thrust
[lbs]
Start
[A]
Max.
[A]
Eff.
[%]
Power factor
6-inch, three-phase permanent-magnet motors
5 3 410 1.15 8.8 8.8 87.2 96 6070
7.5 3 410 1.15 12.4 12.4 89.4 92 6070
10 3 410 1.15 16.2 16.2 90.1 88 6070
15 3 410 1.15 24.5 24.5 92.4 94 6070
20 3 410 1.15 32.2 32.2 92.8 90 6070
25 3 410 1.15 39.0 39.0 93.0 88 6070
30 3 410 1.15 44.8 44.8 93.0 92 6070
40 3 410 1.15 60.0 60.0 93.0 91 6070
50 3 410 1.15 82.6 82.6 92.5 86 6070
CUE 3 x 380 - 480V, UL compliant, maximum recommended fuzes
Motor
power [hp]
CUE 3 x 380 -
500V Nema 4x
outdoor
CUE 3 x 380 - 500
V Nema 1 indoor
Bussmann Type
RK1
Bussmann
Type J
Bussmann Type T SIBA Type RK1
Littelfuse Type
RK1
5 99619042 99616714 KTS-R-20 JKS-20 JJS-20 5017906-020 KLN-R-20
7.5 99619043 99616715 KTS-R-25 JKS-25 JJS-25 5017906-025 KLN-R-25
10 99619044 99616716 KTS-R-30 JKS-30 JJS-30 5012406-032 KLN-R-30
15 99619045 99616717 KTS-R-40 JKS-40 JJS-40 5014006-040 KLS-R-40
20 99619046 99616718 KTS-R-50 JKS-50 JJS-50 5014006-050 KLN-R-50
25 99619047 99616719 KTS-R-50 JKS-50 JJS-50 5014006-050 KLN-R-50
30 99619048 99616720 KTS-R-60 JKS-60 JJS-60 5014006-063 KLN-R-60
40 99619049 99616721 KTS-R-80 JKS-80 JJS-80 2028220-120 KLN-R-80
50 99619051 99616723 KTS-R-100 JKS-100 JJS-100 2028220-125 KLN-R-100
CUE 3 x 380-480V, UL compliant, maximum recommended fuzes
Motor power
[hp]
CUE 3 x 380 - 500V
Nema 4x outdoor
CUE 3 x 380 -
500 V Nema 1
indoor
Ferraz-
Shawmut Type
CC
Ferraz- Shawmut
Type RK1
Bussmann Type
JFHR2
Ferraz- Shawmut J
5 99619042 99616714 ATM-R-20 A6K-20-R FWH-20 HSJ-20
7.5 99619043 99616715 ATM-R-25 A6K-25-R FWH-25 HSJ-25
10 99619044 99616716 ATM-R-30 A6K-30-R FWH-30 HSJ-30
15 99619045 99616717 - A6K-40-R FWH-40
20 99619046 99616718 - A6K-50-R FWH-50 HSJ-50
25 99619047 99616719 - A6K-50-R FWH-50 HSJ-50
30 99619048 99616720 - A6K-60-R FWH-60 HSJ-60
40 99619049 99616721 - A6K-80-R FWH-80 HSJ-80
50 99619051 99616723 - A6K-100-R FWH-100 HSJ-100
41
English (US)
