3 - 3
GRUNDIG Service CINIO AVR 5200 DD
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
Q 19 759550725700 SMD-TRANS T812RLT1/M6
Q 21 759550725600 SMD TRANS 2SA812RLT1/M6
Q 22 830220014300 TRANS.BC 327
Q 81 759550725600 SMD TRANS 2SA812RLT1/M6
Q 82 759550725700 SMD-TRANS T812RLT1/M6
Q 83 759550152800 TRANS KTK117Y
Q 101 759525000600 TRANS.9014 C
Q 102 759525000600 TRANS.9014 C
Q 300 759525000600 TRANS.9014 C
Q 301 759525000700 TRANS.9015 C
Q 302 759525000700 TRANS.9015 C
Q 303 759525000700 TRANS.9015 C
Q 304 759525000700 TRANS.9015 C
Q 305 759525000600 TRANS.9014 C
Q 306 759525000600 TRANS.9014 C
Q 308 759525000700 TRANS.9015 C
Q 309 759550725600 SMD TRANS 2SA812RLT1/M6
Q 405 759525000600 TRANS.9014 C
Q 406 759525000600 TRANS.9014 C
Q 407 759525000600 TRANS.9014 C
Q 408 759525000600 TRANS.9014 C
Q 409 759525000600 TRANS.9014 C
Q 411 759525000600 TRANS.9014 C
Q 428 759525000700 TRANS.9015 C
Q 601 759550723300 TRANS 2SC1016KG-AA
Q 602 759550723300 TRANS 2SC1016KG-AA
Q 603 759550723300 TRANS 2SC1016KG-AA
Q 604 759550723300 TRANS 2SC1016KG-AA
Q 605 759550723200 TRANS 2SC2362KG
Q 606 759550723300 TRANS 2SC1016KG-AA
Q 607 759550723200 TRANS 2SC2362KG
Q 608 759550723400 TRANS 2SD600KE
Q 609 759550723300 TRANS 2SC1016KG-AA
Q 610 759550723200 TRANS 2SC2362KG
Q 613 759550723800 TRANS 2SD1047PE
Q 614 759550723700 TRANS 2SB817PE
Q 615 759550723200 TRANS 2SC2362KG
Q 616 759550723300 TRANS 2SC1016KG-AA
Q 617 759550723300 TRANS 2SC1016KG-AA
Q 618 759550723300 TRANS 2SC1016KG-AA
Q 619 759550723300 TRANS 2SC1016KG-AA
Q 620 759550723200 TRANS 2SC2362KG
Q 621 759550723300 TRANS 2SC1016KG-AA
Q 622 759550723200 TRANS 2SC2362KG
Q 623 759550723400 TRANS 2SD600KE
Q 624 759550723300 TRANS 2SC1016KG-AA
Q 625 759550723200 TRANS 2SC2362KG
Q 628 759550723800 TRANS 2SD1047PE
Q 629 759550723700 TRANS 2SB817PE
Q 630 759550723200 TRANS 2SC2362KG
Q 631 759550723300 TRANS 2SC1016KG-AA
Q 632 759550723300 TRANS 2SC1016KG-AA
Q 633 759550723300 TRANS 2SC1016KG-AA
Q 634 759550723300 TRANS 2SC1016KG-AA
Q 635 759550723200 TRANS 2SC2362KG
Q 636 759550723300 TRANS 2SC1016KG-AA
Q 637 759550723200 TRANS 2SC2362KG
Q 638 759550723400 TRANS 2SD600KE
Q 639 759550723300 TRANS 2SC1016KG-AA
Q 640 759550723200 TRANS 2SC2362KG
Q 643 759550723800 TRANS 2SD1047PE
Q 644 759550723700 TRANS 2SB817PE
Q 645 759550723200 TRANS 2SC2362KG
Q 646 759550723300 TRANS 2SC1016KG-AA
Q 647 759550723300 TRANS 2SC1016KG-AA
Q 648 759550723300 TRANS 2SC1016KG-AA
Q 649 759550723300 TRANS 2SC1016KG-AA
Q 650 759550723200 TRANS 2SC2362KG
Q 651 759550723300 TRANS 2SC1016KG-AA
Q 652 759550723200 TRANS 2SC2362KG
Q 653 759550723400 TRANS 2SD600KE
Q 654 759550723300 TRANS 2SC1016KG-AA
Q 655 759550723200 TRANS 2SC2362KG
Q 658 759550723800 TRANS 2SD1047PE
Q 659 759550723700 TRANS 2SB817PE
Q 660 759550723200 TRANS 2SC2362KG
Q 661 759550723300 TRANS 2SC1016KG-AA
Q 662 759550723300 TRANS 2SC1016KG-AA
Q 663 759550723300 TRANS 2SC1016KG-AA
Q 664 759550723300 TRANS 2SC1016KG-AA
Q 666 759550723300 TRANS 2SC1016KG-AA
Q 668 759550723400 TRANS 2SD600KE
Q 669 759550723300 TRANS 2SC1016KG-AA
Q 670 759550723200 TRANS 2SC2362KG
Q 673 759550723800 TRANS 2SD1047PE
Q 674 759550723700 TRANS 2SB817PE
Q 675 759550723200 TRANS 2SC2362KG
Q 676 759500161100 TRANS.DTC 114 YS
Q 677 759550723600 TRANS 2SA1606E
Q 678 759550723500 TRANS 2SC4159E
Q 679 759550723600 TRANS 2SA1606E
Q 680 759550723500 TRANS 2SC4159E
Q 681 759550723600 TRANS 2SA1606E
Q 682 759550723500 TRANS 2SC4159E
Q 683 759550723600 TRANS 2SA1606E
Q 684 759550723500 TRANS 2SC4159E
Q 685 759550723600 TRANS 2SA1606E
Q 686 759550723500 TRANS 2SC4159E
Q 701 830327533700 TRANS.BC 337-40 GEG.AMMO-PA
Q 950 759525000700 TRANS.9015 C
Q 957 759525000600 TRANS.9014 C
R 17 759550725900 MOW 22 OHM 5% 1W
R 104
S 759550722500 SI-WIDERSTAND 100OHM1/2W5%
R 322 759550726000 DRW 0,1 OHM 5%5W
R 323 759550726000 DRW 0,1 OHM 5%5W
R 628 S 759550724200 SI-WIDERSTAND 3,3 OHM 1/4W
R 629 S 759550724200 SI-WIDERSTAND 3,3 OHM 1/4W
R 630 S 759550724000 SI-WIDERSTAND 100 OHM 1/4W
R 631 S 759550724000 SI-WIDERSTAND 100 OHM 1/4W
R 632 S 759550724100 SI-WIDERSTAND 220 OHM 1/2W
R 670 S 759550724200 SI-WIDERSTAND 3,3 OHM 1/4W
R 671 S 759550724200 SI-WIDERSTAND 3,3 OHM 1/4W
R 672 S 759550724000 SI-WIDERSTAND 100 OHM 1/4W
R 673 S 759550724000 SI-WIDERSTAND 100 OHM 1/4W
R 674 S 759550724100 SI-WIDERSTAND 220 OHM 1/2W
R 712 S 759550724200 SI-WIDERSTAND 3,3 OHM 1/4W
R 713 S 759550724200 SI-WIDERSTAND 3,3 OHM 1/4W
R 714 S 759550724000 SI-WIDERSTAND 100 OHM 1/4W
R 715 S 759550724000 SI-WIDERSTAND 100 OHM 1/4W
R 716 S 759550724100 SI-WIDERSTAND 220 OHM 1/2W
R 754 S 759550724200 SI-WIDERSTAND 3,3 OHM 1/4W
R 755 S 759550724200 SI-WIDERSTAND 3,3 OHM 1/4W
R 756 S 759550724000 SI-WIDERSTAND 100 OHM 1/4W
R 757 S 759550724000 SI-WIDERSTAND 100 OHM 1/4W
R 758 S 759550724100 SI-WIDERSTAND 220 OHM 1/2W
R 792 S 759550724200 SI-WIDERSTAND 3,3 OHM 1/4W
R 793 S 759550724200 SI-WIDERSTAND 3,3 OHM 1/4W
R 794 S 759550724000 SI-WIDERSTAND 100 OHM 1/4W
R 795 S 759550724000 SI-WIDERSTAND 100 OHM 1/4W
R 796 S 759550724100 SI-WIDERSTAND 220 OHM 1/2W
R 900 759550725800 KSW 0617 10 OHM 5% 2W
R 905 759550725800 KSW 0617 10 OHM 5% 2W
R 910 759550725800 KSW 0617 10 OHM 5% 2W
R 915 759550725800 KSW 0617 10 OHM 5% 2W
R 920 759550725800 KSW 0617 10 OHM 5% 2W
RLY 1 759550722900 RELAIS 12VDC/8A2P2T RT42401
POWER BOARD
RLY 1 759550725300 RELAIS 12VDC/1A 2P2TME-2-12
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
( ! )
!
Es gelten die Vorschriften und Sicherheitshinweise
gemäß dem Service Manual "Sicherheit", Mat.-Num-
mer 720108000000, sowie zusätzlich die eventuell ab-
weichenden, landesspezifischen Vorschriften!
The regulations and safety instructions shall be valid
as provided by the "Safety" Service Manual, part
number 720108000000, as well as the respective
national deviations.
RLY 2 759550722900 RELAIS 12VDC/8A2P2T RT42401
POWER BOARD
RLY 2 759550725300 RELAIS 12VDC/1A 2P2TME-2-12
RLY 3 759550725300 RELAIS 12VDC/1A 2P2TME-2-12
RLY 4 759550725300 RELAIS 12VDC/1A 2P2TME-2-12
RLY 5 759550725300 RELAIS 12VDC/1A 2P2TME-2-12
RLY 101 S 759550723000 RELAIS 12VDC/10ASPST OMI-SS
S 1 759550722100 ENCODER ROTARY 12MM E160224/
VOLUME
S 2 759550722000 ENCODER ROTARY 7MME1602243B
TON CONTOL
SW 100 S 759550723100 NETZSCHALTER 4A/128A250VAC
SW 700 594003050000 TIPPTASTE (KHH 10910)
SW 701 594003050000 TIPPTASTE (KHH 10910)
SW 702 594003050000 TIPPTASTE (KHH 10910)
SW 703 594003050000 TIPPTASTE (KHH 10910)
SW 704 594003050000 TIPPTASTE (KHH 10910)
SW 705 594003050000 TIPPTASTE (KHH 10910)
SW 707 594003050000 TIPPTASTE (KHH 10910)
SW 708 594003050000 TIPPTASTE (KHH 10910)
SW 709 594003050000 TIPPTASTE (KHH 10910)
SW 710 594003050000 TIPPTASTE (KHH 10910)
SW 711 594003050000 TIPPTASTE (KHH 10910)
SW 712 594003050000 TIPPTASTE (KHH 10910)
SW 713 594003050000 TIPPTASTE (KHH 10910)
SW 714 594003050000 TIPPTASTE (KHH 10910)
SW 715 594003050000 TIPPTASTE (KHH 10910)
SW 716 594003050000 TIPPTASTE (KHH 10910)
SW 717 594003050000 TIPPTASTE (KHH 10910)
SW 718 594003050000 TIPPTASTE (KHH 10910)
SW 719 594003050000 TIPPTASTE (KHH 10910)
SW 720 594003050000 TIPPTASTE (KHH 10910)
T 1 S 759550722700 NETZTRAFO T96-0222010-51
T 101 S 759550722800 TRAFO STANDBY T28-0222011-0
U 1 759550724800 IC CS49326 PLCC
U 2 759550724300 IC 74VHC245M
U 3 759550724300 IC 74VHC245M
U 4 759550724600 IC CS5333KZ 24BIT96KHZ
U 4 759550726500 SMD IC QFP M61516FP 7.1CH
U 5 830571543400 SMD IC CS4334KS SO8 CRYSTAL
U 6 830575983300 SMD IC LM833D
U 7 830575983300 SMD IC LM833D
U 8 830575983300 SMD IC LM833D
U 9 830575983300 SMD IC LM833D
U 10 759550724500 IC CS4360KZ 24BIT
U 11 759550724400 IC 74VHC574M SO-20
U 12 759550724400 IC 74VHC574M SO-20
U 13 759550724700 IC AT27LV010A-90JC
U 14 759550724900 SMD IC CS8415A
VFD 1 759550720400 DISPLAY 2COLORS 12BT-11
XT 1 759550725000 QUARZ 12.288MHZ 50PPM 8PIN
Y 701 759550721900 QUARZ 5.MHZ CSTLS5M00G53-BO
