3 - 2
GRUNDIG Service CINIO AVR 5200 DD
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
Ersatzteilliste
Spare Parts List
CINIO AVR 5200 DD
HIFI/AUDIO
MATERIAL-NR. / PART NO.: 755112005000
BESTELL-NR. / ORDER NO.: GLO0150 ALU/SILBER/ALU/SILVER
ǵ
4 / 2003
POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION
POS. NO. FIG. PART NUMBER QTY.
d©
755112005000 CINIO AVR 5200 DD ALU/SILBER CINIO AVR 5200 DD ALU/SILVER
KEIN E-TEIL NO SPARE PART
0001.000 1 759550720100 KNOPF LAUTSTAERKE KNOB VOLUME
0002.000 1 759550720200 BLENDE ALU/SILBER MASK ALU/SILVER
0003.000 1 759550720300 KNOPF NETZ KNOB POWER
0005.000 1 759550720400 DISPLAY DISPLAY
0006.000 1 759550720500 LINSE DISPLAY LENS DISPLAY
0009.000 1 759550720600 2 TASTENSATZ MODE KEY SET MODE
0013.000 1 759550722200 KOPFHOERERBUCHSE 6.35MM HEADPHONE SOCKET 6.35MM
0017.000 1 759550720700 10 FOLIE WAERMELEITEND 25X20X0,3 FOIL HEAT CONDUCTING 25X20X0,3
0023.000 1 759550721400 GEH-OBERTEIL CABINET TOP
0029.000S1 759550720800 NETZKABEL POWER CABLE
0040.000 1 759540158100 ZUGENTLASTUNG STRESS RELIEF
0043.000 1 759550720900 STOESSEL TAPPED
0047.000 1 759550721000 2 TASTENSATZ TUNER KEY SET TUNER
0050.000 1 759550721100 TASTENSATZ PROGRAMM KEY SET PROGRAM
0052.000 1 759550721200 KNOPF SET UP KNOB SET UP
0053.000 1 759550721300 FOLIE WAERMELEITEND FOIL HEAT CONDUCTING
0064.000 1 759550726800 2 VENTILATOR 12VDC0.16A 50X50X10 FAN 12VDC0.16A 50X50X10MM
0075.000 1 759550726700 FM-TUNER 75OHM KST-M1114FW1-20 FM-TUNER 75OHM KST-M1114FW1-20
0100.000 296420614900 TP 50 A FERNBEDIENUNG TP 50 A REMOTE CONTROL
720114031000 BEDIENUNGSANLEITUNG D/GB/F/I/P OPERATING INSTRUCTION D/GB/F/I/P
720114031100 BEDIENUNGSANLTG. E/NL/DK/S/FIN OPERATING INSTRUCTION E/NL/DK/S/FIN
720107728000 SERVICE MANUAL D /GB SERVICE MANUAL D/GB
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
C 055 845299510700 ELKO 2200UF 20% 16V CA
C 101
S 759901004000 MKP 0,22UF 20% 250AVC
C 102
S 759901004000 MKP 0,22UF 20% 250AVC
C 103 759550722400 ELKO 2200UF25V20%85GRAD RM5
C 115 759540301000 ELKO 1000UF 20% 10V
C 119 759540301000 ELKO 1000UF 20% 10V
C 120 759540301000 ELKO 1000UF 20% 10V
MAIN BOARD
C 120 759545039200 ELKO 8200UF M 63V R23DPL
C 121 759545039200 ELKO 8200UF M 63V R23DPL
C 162 759540301000 ELKO 1000UF 20% 10V
C 317 759550722400 ELKO 2200UF25V20%85GRAD RM5
C 318 759550722400 ELKO 2200UF25V20%85GRAD RM5
C 704 759540301000 ELKO 1000UF 20% 10V
D 1 830921504500 DIODE 1N4148 AV619 -GA
MAIN BOARD
D 1 759813509100 DIODE 1SS355
D 2 830921504500 DIODE 1N4148 AV619 -GA
D 3 830921504500 DIODE 1N4148 AV619 -GA
D 4 830921504500 DIODE 1N4148 AV619 -GA
D 4 830921510400 DIODE 1 N 4002 <<< -GA
POWER BOARD
D 5 830921510400 DIODE 1 N 4002 <<< -GA
POWER BOARD
D 5 830921504500 DIODE 1N4148 AV619 -GA
D 6 759550725400 DIODE SR160 SHKY
D 6 830921510400 DIODE 1 N 4002 <<< -GA
POWER BOARD
D 7 830921510400 DIODE 1 N 4002 <<< -GA
POWER BOARD
D 7 759550725400 DIODE SR160 SHKY
D 8 759550725400 DIODE SR160 SHKY
D 9 759550725400 DIODE SR160 SHKY
D 10 830921510400 DIODE 1 N 4002 <<< -GA
D 14 830921504500 DIODE 1N4148 AV619 -GA
D 15 830921504500 DIODE 1N4148 AV619 -GA
D 101 830921510400 DIODE 1 N 4002 <<< -GA
D 102 759550722300 DIODE SR160 DO41 1A/60V
D 103 759550722300 DIODE SR160 DO41 1A/60V
D 104 830921510400 DIODE 1 N 4002 <<< -GA
D 105 830972027000 Z DIODE 27 C 0,5W
D 107 830921510400 DIODE 1 N 4002 <<< -GA
D 111 830970753200 Z-DIODE ZPD6,8 ITT/MOT/ BZX
D 112 759550725500 DIODE KGK15G 15A400V
POWER BOARD
D 112 759550722300 DIODE SR160 DO41 1A/60V
D 113 759550722300 DIODE SR160 DO41 1A/60V
D 300 830921510400 DIODE 1 N 4002 <<< -GA
D 301 830921510400 DIODE 1 N 4002 <<< -GA
D 302 830921510400 DIODE 1 N 4002 <<< -GA
D 303 830921510400 DIODE 1 N 4002 <<< -GA
D 304 830921510400 DIODE 1 N 4002 <<< -GA
D 306 830972005200 Z DIODE 5,1 C 0,5W
D 400 830970753200 Z-DIODE ZPD6,8 ITT/MOT/ BZX
D 401 830970753200 Z-DIODE ZPD6,8 ITT/MOT/ BZX
D 408 830921504500 DIODE 1N4148 AV619 -GA
D 409 830921504500 DIODE 1N4148 AV619 -GA
D 410 830921504500 DIODE 1N4148 AV619 -GA
D 411 830921504500 DIODE 1N4148 AV619 -GA
D 412 830921504500 DIODE 1N4148 AV619 -GA
D 413 830921504500 DIODE 1N4148 AV619 -GA
D 414 830921504500 DIODE 1N4148 AV619 -GA
D 415 830921504500 DIODE 1N4148 AV619 -GA
D 416 830921504500 DIODE 1N4148 AV619 -GA
D 417 830921504500 DIODE 1N4148 AV619 -GA
D 424 830921504500 DIODE 1N4148 AV619 -GA
D 601 830921504500 DIODE 1N4148 AV619 -GA
D 602 830921504500 DIODE 1N4148 AV619 -GA
D 603 830921504500 DIODE 1N4148 AV619 -GA
D 604 830921504500 DIODE 1N4148 AV619 -GA
D 605 830921504500 DIODE 1N4148 AV619 -GA
D 606 830921504500 DIODE 1N4148 AV619 -GA
D 607 830921504500 DIODE 1N4148 AV619 -GA
D 608 830921504500 DIODE 1N4148 AV619 -GA
D 609 830921504500 DIODE 1N4148 AV619 -GA
D 610 830921504500 DIODE 1N4148 AV619 -GA
D 701 830970753200 Z-DIODE ZPD6,8 ITT/MOT/ BZX
D 704 830921504500 DIODE 1N4148 AV619 -GA
D 711 830972005500 Z DIODE 5,6 B 0,5W
D 716 830921510400 DIODE 1 N 4002 <<< -GA
F 1
S 831562000300 SI 5X20 T2A L 250V
F 101 S 831562200300 SI 5X20 T3,15A L 250V
F 105 S 831562000300 SI 5X20 T2A L 250V
F 106 S 831562000300 SI 5X20 T2A L 250V
IC 1 759550725200 SMD IC HCF4052BMI
IC 2 830575983300 SMD IC LM833D
IC 3 830575983300 SMD IC LM833D
IC 203 759550726400 SMD IC NJM2296M
IC 301 830575983300 SMD IC LM833D
IC 302 759550726300 IC NJM7912
IC 302L 830575983300 SMD IC LM833D
IC 302R 830575983300 SMD IC LM833D
IC 303 759550726200 IC NJM7812
IC 305 759813162800 IC NJM 7805 FA
IC 306 830520431700 IC LM317T NSC/MOT/SGS
IC 401 830575983300 SMD IC LM833D
IC 402 830575983300 SMD IC LM833D
IC 403 830575983300 SMD IC LM833D
IC 404 759880657000 IC BH3544F
IC 701 759550721700 IC UPD78PO208GF-3BA
IC 702 759550721800 IC AT24C02-10PI-2.7 EEPROM
IR 1 759550721600 IC STGP1UM280RK36KHZ
J 3 759550726600 SCHIEBESCHALTER 1P2T DC20V0
L 101 S 759550722600 ENTSTOERDROSSEL5MHEE25FTU25
L 701 759880073000 DR 0309 100UH 10% GA LALO3T
LED 5 759550721500 LED-DIODE ROT2X8MM2R4HW2CIR
MR 601 759550723900 DRW 2X0,27 OHM 5W 5%
MR 602 759550723900 DRW 2X0,27 OHM 5W 5%
MR 603 759550723900 DRW 2X0,27 OHM 5W 5%
MR 604 759550723900 DRW 2X0,27 OHM 5W 5%
MR 605 759550723900 DRW 2X0,27 OHM 5W 5%
NTC 759550726100 NTC 10KOHM3%620MM
Q 1 759525000600 TRANS.9014 C
Q 2 759525000600 TRANS.9014 C
Q 3 759525000600 TRANS.9014 C
Q 4 759880562900 TRANS KRC107S
Q 4 759525000600 TRANS.9014 C
Q 5 759525000600 TRANS.9014 C
Q 6 759525000600 TRANS.9014 C
Q 7 759525000600 TRANS.9014 C
Q 8 759525000600 TRANS.9014 C
Q 9 759525000600 TRANS.9014 C
Q 10 759525000600 TRANS.9014 C
Q 11 759525000700 TRANS.9015 C
Q 12 759550725100 SMD IC 2SA812RLT1/M6
Q 13 759525000700 TRANS.9015 C
Q 14 759525000700 TRANS.9015 C
Q 15 759550725100 SMD IC 2SA812RLT1/M6
Q 16 830220014300 TRANS.BC 327
Q 17 759550725600 SMD TRANS 2SA812RLT1/M6
