Grundig Xentia LXW 102-8625 REF - Controls and Input Ports; Included Accessories

11
User Guidance Information
Back View
Controls and Functions
❿ S-Video 1
󱆌 SCART (Full SCART, Half SCART)
󱆍 Audio out
󱆎 ANT - Antenna Terrestrial
󱆏 Audio Input (Composite 2/ S-Video 2)
󱆐 Composite 2
󱆑 S-Video 2
󱆒 Headphone
❶ AC Input
❷ RS-232C Terminal
❸ Analog RGB (D-SUB)
❹ Digital RGB (DVI-D)
❺ Component 1
❻ Component 2
❼ Audio Input (Component 1, 2, PC/ DVI)
❽ Audio Input (Composite 1/ S-Video 1)
❾ Composite 1
❻
󱆏
󱆐
󱆑
󱆒
Audio out Cable
Accessories
● The configuration of the components may look different from the following illustration.
Power Cord
Antenna Cable
User's Guide
Battery 1.5V( AAA
×2)
User's Guide
SCART Cable
(Europe+Middle East only)
Remote Control
❶❷ ❸❹❺❼❽❾❿ 󱆌 󱆍󱆎
