19
Features and Specifications
• Zero negative feedback
• True Dual Mono configuration
• Fully discrete, DC-coupled Class A circuit topology
• Microprocessor-controlled 43-step fully balanced relay volume attenuator for best sonic
performance based on a minimalist contingent of ultra-precision resistors
• High-speed, discrete, single-ended Class A input buffer for best possible sonic performance
• Optional PCM/DSD DAC module with one USB, 2 x SPDIF, 1 AES and 1 optical input.
PCM up to Fs = 384 kHZ, DSD up to DSD512
• Optional MM/MC PS2 / PS2-S phonostage module based on the legendary Legato
phonostage
• Local shunt regulators for optimal noise suppression
• Input level matching to prevent abrupt volume changes
• Ultra-short signal path
• Minimal internal wiring
• Gold-plated Neutrik XLR sockets for two balanced sources and 1 output
• Gold-plated phono sockets with Teflon insulation for 3 inputs and 2 outputs
• Fixed-level AV throughput, balanced or single-ended, for uncompromising integration with
separate surround preamplifier
• Large Vacuum Fluorescent Display for easy legibility
• Adjustable display lighting (100/75/50/25%, Off)
• Backlit touch-sensitive front panel controls
• 12 V DC link input and output
• Green Bias link output for automatic Green Bias control with any Gryphon power amplifier
• Stylish infrared remote control
• Flash memory upgrades possible via PC or Key-fob
• EU CE approval
• Standby current consumption < 0.5 W
• Designed and built in Denmark
Specifications:
• +18 dB gain, max.
• Output impedance: 15 Ohm XLR, 22.5 Ohm RCA
• Frequency bandwidth (-3 dB): 0.1 Hz – 1 MHz
• Power supply capacity: 2 x 26,000 µF
• Input impedance, balanced (20 Hz – 20 kHz): 50 kOhm
• Input Impedance, single-ended (20 Hz – 20 kHz): 25 kOhm
Dimensions:
• 47 x 16.5 x 38.5 cm (WxHxD), 13.4 kg net.
Specifications can be changed without notice.
