3.7.1.1 Controller
Refer to the certified electrical drawing(s) for specific wiring requirements.
3.7.1.2 Solenoid Valve Coils
110/120 VAC, 50/60 Hz, Single Phase, 50 Watts.
Optional - 220/240 VAC, 50/60 Hz, Single Phase, 90 Watts.
3.7.1.3 Hydraulic Tank Heater (Optional)
120 VAC, 50/60 Hz, Single Phase, 500 Watts.
3.7.1.4 Hydraulic Pump Motor
Hydraulic Power Unit
Horsepower
Voltage & Phase
60 HZ
Amps
3 HP TP Comp & Core 230 1PH 14.0
3 HP TP Comp & Core 230/460 3PH 8.29/4.14
3 HP TP Comp & Core 575 3PH 3.32
5 HP STP Comp & Core 230 1PH 21.5
5 HP STP Comp & Core 230/460 3PH 13.2/6.6
5 HP STP Comp & Core 575 3PH 5.28
NOTE:
THE MOTOR CHART AMPERAGES SHOWN ARE FOR REFERENCE ONLY. VERIFY BY CHECKING
MOTOR NAMEPLATE.
