IV. OPERATIONS AND ADJUSTMENTS
DANGER
FAILURE TO OBSERVE ALL SAFETY RULES, WRITTEN AND IMPLIED, AND THOSE
SUGGESTED BY COMMON SENSE, CAN RESULT IN DEATH, SERIOUS INJURY, AND /OR
EQUIPMENT DAMAGE. LOCKOUT POWER BEFORE PERFORMING ANY MAINTENANCE.
4.1 Operators Control Components And Their Functions
FIGURE 4-1, STANDARD NEMA 12 OPERATORS CONTROL PANEL DETAIL
Refer to the certified electrical drawing(s) for dimensions on control panels with optional features.
