7.4.1 Truck Probe Parts Listing
TP STP
ITEM NO. DESC QTY PART NO QTY PART NO
1 MAIN STAND WELDMENT 1 531748 1 531749
2 CHAIN GUARD SMALL HALF 1 531750 1 531752
3 CHAIN GUARD LARGE HALF 1 531751 1 531753
4 DRIVE SPROCKET 1 35688 1 35688
5 PIVOT TUBE WELDMENT 1 531900 1 543931
6 RYERTEX TEE BUSHING 2 518911 2 529628
7 ZERK BOLT ½-13UNC (1/2 TP & 1.25STP) 2 531755 2 529787
8 BOOM SHAFT (1” TP & 1-1/4” STP) 1 35176 1 XE8931
9 4 BOLT FLANGE BEARING(1”TP & 1.25”STP) 2 34792 2 24058
10 INNER BOOM WELDMENT 1 531885 1 531887
10A DRILL BUSHING ¾ ID x 1 OD x 1 LG - - 2 543908
11 OUTER BOOM WELDMENT 1 531886 1 531888
12 IN/OUT RYERTEX BEARING PLATE 1 531882 1 531883
13 HEX HEAD BOLT ¾-10UNC 1 531884 1 542295
14 BUSHING 1.50 OD x 1.00 ID x 1 LG DURALON - - 1 531395
15 BUSHING 1.50 OD x 1.00 ID x 0.5 LG DURALON - - 2 543933
38 BUSHING 1.50 OD x 1.00 ID x 1 LG DURALON 1 531395 2 531395
ITEM NO. PART NO DESCRIPTION QTY
STAND & PIVOT TUBE COMPONENTS
16 35684 CYLINDER HYD 3 BORE X 24 STROKE 1
17 34029 CHAIN ROLLER NO. 60-H A/R
18 34758 CHAIN LINK NO. 60-H CONNECTOR 1
19 34033 CHAIN LINK NO. 60-H OFFSET A/R
20 35687 HYD TORQUE MOTOR W/ 1.00 SHAFT 1
21 531754 TP & STP HYD MOTOR SLIDE PLATE 1
22 35628 ELBOW 90 M-F ½ MPT x ½ FPT STL 2
23 35623 PIPE NIPPLE ½ NPT X 2 LG BLACK 2
24 35629 ADJ FLOW CONTROL ½ NPT 15 GPM 2
25 36298 GEASE ZERK STRAIGHT ¼-28 UNF 2
26 522911 PIVOT STOP HR BAR 2 X 1.5 X 1.5 2
27 531935 BULKHEAD BRACKET DUAL LANE 1
28 516539 PAINT DTM GRAY TOUCH UP SPRAY CAN A/R
BOOM COMPONENTS
31 35685 CYLINDER HYD 1-1/2 BORE X 48 STROKE 1
32 531934 INNER VAC TUBE 60.00 LG A/R
33 531933 OUTER VAC TUBE 54.25 LG A/R
34 527072 INNER VAC TUBE MTG BRKT A/R
35 527071 OUTER VAC TUBE MTG BRKT A/R
36 527073 FITTING FLEX HOSE 1.50 ID A/R
37 34506 WORM CLAMP 1-9/16 TO 2-1/2 A/R
7 FT PROBE 9 FT PROBE
ITEM NO. DESC QTY PART NO PART NO
41 CORE PROBE 1 531745 531746
42 COMPLETE COMP PROBE ASSY 1 531906 531907
43 PROBE ASSY (INCLUDES 44 & 46) 1 35593 35774
44 INNER PROBE WELDMENT 1 35590 512140
