29
ITEM NO. PART NO DESCRIPTION QTY
45 530288 URETHANE PROBE TIP REPLACEMENT KIT 1
46 - - -
47 531904 RAIN COVER TOP COMP PROBE 1
48 531905 RAIN COVER FRONT COMP PROBE 1
49 35702 COUPLING ACTUATOR 1
50 35686 HYD ROTARY ACTUATOR 180 DEG 1
51 35611 VACUUM HOSE 1-1/2” ID A/R
COLLECTION CABINET COMPONENTS
61 35790 COLLECTION BOX FRAME 1
62 512871 COLLECTION BOX SCREEN 1
63 525643 COLLECTION BOX DOOR 1
64 523981 COLLECTION BOX WINDOW 1
65 34670 1/8 THICK NEOPRENE 4.88 X 6.00 1
66 530552 TP CYCLONE 1
67 530553 TP CYCLONE COLLECTION CHAMBER 1
68 530554 TP CYCLONE 1.50 OD OUTLET ELBOW 1
SINGLE 2-STAGE VAC UNIT COMPONENTS
71 34783 VAC HOUSING SINGLE 2-STAGE 1
72 35606 VAC HOUSING COVER 1
73 35940 VAC OUTLET 1.50 OD 90 DEG 1
74 35607 VAC GASKET 9.7X 9.7 X 1 1
75 35532 2-STAGE VAC MOTOR W/ TANGENTIAL DISCHARGE 1
DUAL VAC UNIT COMPONENTS
76 35607 VAC GASKET 9.7X 9.7 X 1 2
77 34498 HOSE 2.0 ID PLASTIFLEX A/R
78 35212 VAC HOSE ADAPTER 2.0” OD 1
79 35605 VAC HOSE ADAPTER 1.5” OD 1
80 34069 PANEL LOCK W/ KEY 1
81 515495 VAC HOUSING DUAL 2 OR 3-STAGE 1
82A 35940 VAC OUTLET 1.50 OD 90 DEG 1
82B VAC OUTLET 2.38 OD 90 DEG 1
83A 35532 2-STAGE VAC MOTOR W/ TANGENTIAL DISCHARGE 2
83B 529239 3-STAGE VAC MOTOR W/ TANGENTIAL DISCHARGE 2
HYDRAULIC POWER UNIT COMPONENTS
91 531744 HYD UNIT HOUSING W/ DOORS 1
92 35786 HYD UNIT COVER 1
93 514539 NEMA 1 ELECTRICAL JUNCTION BOX 10 X 8 X 4 1
94 514538 SUB PANEL 1
95 34605 TERMINAL BLOCK 10 SPACE 1
96 34726 ½” CONDUIT LOCK RING 4
97 35576 STRAIN RELIEF CONNECTOR ½ NPT 8
98 35575 16/3 S CONDUCTOR CORD 20
99 35041 FIT PIPE PLUG 1 NPT BLACK 1
100 35767 INTANK FILTER STRAINER 1
101 35776 FILLER FILTER BREATHER 1
102 35619 ½” FNPT OIL FILTER & BLOCK 1
103 35683 BLACK 90 DEG STREET ELBOW ½ NPT 1
104 35943 BLACK 90 DEG STREET ELBOW ¾ NPT 2
105 35624 BLACK PIPE PLUG ½ NPT 3
