GST IFP4M - Fire Alarm Control Panel Loop Configuration

Fire Alarm Control Panel
Loop length under typical loop devices configuration
7
Sample
configuration 1
Sample
configuration 2
Sample
configuration 3
Sample
configuration 4
Number of
smoke detectors 60 80 100 120
Number
of heat detectors 8 10 10 15
Number
of MCPs 8 10 10 15
Number
of input modules 4 4 4 10
Number
of output modules 4 4 4 10
Number
of loop isolators 2 3 4 5
Total Devices per loop
84 108 128 170
14AWG/2.0mm2
4000m 3300m 2600m 2000m
15AWG/1.65mm2
3500m 2700m 2200m 1700m
16AWG/1.3mm2
3000m 2300m 1900m 1400m
17AWG/1.0mm2
2000m 1500m 1200m 900m
