5
Bowen's Mount Release Slider
Heat Dissipation And Cooling Vents
1/4 Thread
Display
Knob
Power Button
Charging Port
LED Light Chip
1
PRODUCT STRUCTURE DIAGRAM
INSTALLATION METHOD
Insert the standard cover into the socket of the light accordingly, and then turn it
slightly clockwise to lock the Bowen's reflector to the light. Push the slider back and
rotate the Bowen's reflector counterclockwise to remove it from the light.
