GW Instek GDS-1000B Series User Manual

GETTING STARTED
5
GETTING STARTED
App Overview
Background
The GDS-1000B comes pre-installed with a number
of apps. Optional apps can also be downloaded
from the GW Instek website free of charge at
www.gwinstek.com.
Included
Applications
Go/No-Go
The Go/No-Go application can be
used to set threshold boundaries
for input signals. Go/No-Go tests
to see if a waveform will fit inside
a user-specified maximum and
minimum amplitude boundary
(template).
Mount Remote
Disk*
This app allows the scope to
mount a network share drive.
* 4 channel models only.
Optional
Applications
Digital Filter
Adds a digital low or high pass
filter to any of the input channels.
Each filter can have a user-defined
cutoff frequency set.
DVM
The DVM application displays a
digital voltage meter readout that
floats on the top left-hand side of
the screen.
