GW Instek GDS-1000B Series User Manual

GDS-1000B Series Datalog App User Manual
10
USING THE DATA
LOGGER
Background
The Data Log app will log the current waveform
data or screenshot at set intervals for a set duration
of time.
Basic Features:
 Log up to 100 hours of images or waveform
data.
 Interval times of up to 2 seconds (waveform)
or 5 seconds (images).
Example
Panel Operation
1. Choose the Data Log application
from the APP menu. See page 9.
