GW Instek GDS-1000B Series - Running Applications

GETTING STARTED
9
Running Applications
Background
The APP function can host a number of different
applications, some of which as pre-installed and
some of which are installed as optional extras.
Panel Operation
1. Press the APP key.
APP
2. Press APP from the bottom menu.
3. Scroll through each application using the
Variable knob.
4. Select an application by pressing
the Select key twice.
Select
×2
