GDS-200 & GDS-300 Series User Manual

GETTING STARTED

This chapter will allow you to quickly set up a

GDS-200 or GDS-300 series oscilloscope and run

over the basic operation and features.

Before you can get started, you will need to check

the package contents (standard accessories, page

14). After the contents are checked the Overview

section will describe all the major features and

functions of the oscilloscopes in the GDS-200 and

GDS-300 series. The Appearance section will go

over the front, rear and side panels of the

instrument. The Display Overview will give a

brief introduction to the display and how the

display changes depending on the current

function, orientation or mode. Lastly the Getting

Started section will explain how to turn on the

instrument, explain how to set up the instrument,

and go over the gestures and operating

conventions that are used with the capacitive

touch panel on the unit.

GDS-200 and GDS-300 Series Overview ........................... 12

Series Lineup ............................................................................................................ 12

Main Features ........................................................................................................... 12
