GDS-200 & GDS-300 Series User Manual
90
Steps
1. Press the M (Measure) icon in the menu bar at
the bottom of the display.
2. The minimized view will appear above the
menu bar.
3. To toggle between the minimized and
maximized view, tap anywhere within the area
that the automatic measurements are displayed.
4. To remove the automatic measurements from
the display*, press the M (Measure) icon again
in the menu bar.
Measure icon
Automatic measurement
area (minimized shown)
Selecting an Automatic Measurement
Background
Automatic measurements can be accessed from
the drop down menu or from the menu bar at
the bottom of the screen.
