GW Instek GPT-9801 Quick Start Guide

GPT-9000 Series Quick Start Guide
18
The step will be removed from the table as soon as
the DEL soft-key is pressed.
Save Page View
 To save, press the EDIT/SAVE key.
EDIT/SAVE
The tester will return to the VIEW status.
Cancel and Exit Page View
 To exit and cancel any changes, press the ESC key.
ESC
The tester will return to the VIEW status.
Common Utility Settings
Description
The Common Utility menu is accessed by
pressing the UTILITY key when the tester is in
VIEW status. This utility controls the LCD,
buzzer, interface and control settings. These
settings are system wide.
The Common Utility settings include:
LCD: Contrast, Brightness
BUZZ: Pass Sound, Fail Sound
INTR: Interface (RS232, USB), Baud
CTRL: Start Ctrl (FRONT PANEL, SIGNAL
I/O, REMOTE CONNECT), Double
Action, Key Lock, Interlock
Utility selection
K e y L o k : Oc F F
S t a r t t r lC
D o u b l e A c t i no
L CD B U Z Z N T EI R C T R L
:
: F RO N T P A N
MOC MO UN T I L I T Y
E L
FO F
I N T E R L C K :O O FF
