GW Instek GPT-9801 Quick Start Guide

GPT-9000 Series Quick Start Guide
8
Go to EDIT Status
 Press the EDIT/SAVE key.
EDIT/SAVE
Go to READY Status
 Press the STOP button when a MANU test or AUTO
test has been selected.
STOP
AUTO/MANU Mode
Description
MANU mode is used to create and execute
manual tests.
AUTO mode is used to create automatic tests
that execute up to 16 steps (manual tests)
sequentially.
G
B
I R A CW D CW
E
F R E Q = 0 H z 6
0 100
k V
RA C = F FO
EIV
MT I E = 0 0 1 . 0 SR
0 0 m AER F =# 0 .0
1 . 0 0 m AIH ES = 0T
0 0 . 1 S0A M P =R
A U T O = 0 0 1 - 0 0 2
W
MM A UN N A_2M A N U = * * * - 0 0
AUTO mode
MANU mode
m A
Switch Between AUTO/MANU Mode
 Press and hold the MANU/AUTO key to switch
between AUTO and MANU when the tester is in
VIEW status.
MANU/AUTO
