GW Instek MFG-2000 Series Quick Start Guide

MFG-2000 Quick Start Guide
10
 DWR (Direct Waveform Reconstruction)
capability
 Ability to edit waveforms without a PC
 -60dBc low distortion sine wave
Features
 Sine, Square, Ramp, Pulse, Noise waveforms
 Internal and external LIN/LOG sweep with
marker output
 Int/Ext AM, FM, PM, FSK, SUM, PWM
modulation
 Burst function with internal and external
triggers
 42Vpk signal ground chassis isolation
 Pulse waveform with configurable rise times &
fall times
 Store/recall 10 groups of setting memories
 Output overload protection
Interface
 USB interface as standard, LAN interface(MFG-
22XX only)
 4 inch Color TFT LCD (480 X 272) graphical user
interface
 AWES (Arbitrary Waveform Editing Software)
PC software

GW Instek MFG-2000 Series Specifications

General

Brand	GW Instek
Model	MFG-2000 Series
Category	Inverter
Language	English
