9. Press MOD, AM (F1),
Source (F1), INT (F1).

 

10. Press the Output key.
ASK
Example: ASK modulation. 50% duty cycle. 1kHz sine carrier wave. 10Hz rate . Internal
source.
Output:

      
      
     
    
   
      
  

      

      
      
      
1. Press MOD and then
select ASK(F2).

K
2. Press Waveform and
select Sine(F1).


Input: N/A
3. Press the Freq/Rate
key, followed by 1 +
kHz (F5).

kz
Q
4. Press the MOD key,
select ASK(F2), ASK
Rate (F3).

K Ka
5. Press 1+ 0 + Hz (F2)


z
6. Press the MOD key,
select ASK(F5), ASK
Ampl(F2).
7. Press
5+0+0+mVpp(F5).
D


%


z

