GW Instek MFG-2000 Series - ARB-Output Infinite Cycles; ARB-Output Marker

MFG-2000 Quick Start Guide
52
ARB–Output Infinite Cycles
Example: ARB Mode, output N cycle, start 0, length 1000, cycles
infinite.
Output:

      
      
     
    
   
      
  

      

      
      
      
1. Press ARB,
Output(F6).

O
2. Press Start (F1), 0 +
Enter (F5),
Return(F6).

Ea

3. Press Length (F2),
1+0+0+0, Enter (F5),
Return (F6).

gh


Ea
E 
4. Press Infinite(F5),
Return(F6).
 
ARB–Output Marker
Example: ARB mode, output marker, Start 30, Length.
Output:

      
      
     
    
   
      
  

      

      
      
      
1. Press ARB, Output
(F6), Marker (F3).

O ak
2. Press Start (F1), 3+0,
Enter (F5), Return.

a

E 
3. Press Length (F2), 8 +
0, Enter (F5), Return.

gh

E 
