MFG-2000 Quick Start Guide
34
4. Press the AMPL key
then 5 +VPP (F6).

V

5. Press the Output key.
Sine Wave
Example: Sine Wave, 10Vpp,100kHz
Output:

      
      
     
    
   
      
  

      

      
      
      
Input: N/A
1. Press the Waveform
key and select Sine
(F1).


2. Press the Freq/Rate
key, followed by 1 + 0
+0 + kHz (F5).
Q

 
kz
3. Press the AMPL key,
followed by 1 + 0
+VPP (F6).


V

4. Press the output key.
