GW Instek MFG-2000 Series Quick Start Guide

MFG-2000 Quick Start Guide
74
MFG-2000 Series Specifications
The specifications apply when the function generator is powered on
for at least 30 minutes under +18°C~+28°C.
MFG-2000 series specific functions
CH1
CH2
25MHz
Pulse
Generator
RF
Generator
(function
with ARB)
Power
Amplifier
Modulation
/Sweep/Burst/Fr
equency.Counter
Function With
200MSa/sARB
Function With
200MSa/sARB
MFG-2110
●10MHZ
●
MFG-2120
●20MHZ
●
MFG-2120MA
●20MHZ
●
●
●
MFG-2130M
●30MHZ
●
●
MFG-2160MF
●60MHZ
●
●160MHZ
●
MFG-2160MR
●60MHZ
●
●320MHZ
●
MFG-2230M
●30MHZ
●30MHZ
●
●
MFG-2260M
●60MHZ
●60MHZ
●
●
MFG-2260MFA
●60MHZ
●60MHZ
●
●160MHZ
●
●
MFG-2260MRA
●60MHZ
●60MHZ
●
●320MHZ
●
●
CH1/ CH2
Waveforms
Standard
Sine,Square,Ramp,Pulse,Noise
Arbitrary
Functions
ARB function
Built-in
Sample Rate
200 MSa/s
Repetition Rate
100MHz
Waveform Length
16k points
Amplitude Resolution
14 bits
Non-Volatile Memory
10sets 16k points(1)
User-defined output section
From point 2~16384 (optional)
User-defined output marker
section
From point 2 ~ 16384(optional)
Output mode
1~1000000 cycles or infinite mode
Built-in Arbitrary
Absatan,Abssine,Abssinehalf,Amp
alt,Attalt,Diric.even,Diric.odd,Gaus
puls,Havercosine,Haversin,N_puls
e,Negramp,Rectpuls,Roundhalf,Sa
wtoot,Sinetra,Sinever,Stair_down,S
tair_ud,Stair_up,Stepresp,Traperia,
Tripuls,Airy,Bessel,Beta,Gamma,Le
gendre,Neemann,Arccos,Arccot,Ar
ccsc,Arcsec,Arcsin,Arcsinh,Arctan,
Arctanh,Cosh,Cot,Csc,Dlorentz,ex
pofall,exporise,gauss,ln,lorentz,Se
c,Sech,Sinc,Sinh,Sqrt,Tan,Tanh,Xs
quare,Barthannwin,Bartlett,Blackm
an,Bohmanwin,Chebyshev,Flatttop
