QUICK REFERENCE
75
win,Hamming,Hann,Hanning,Kais
er,Triang,Tukeywin
Frequency
Characteristics
Range
Sine 60MHz(max)
Square 25MHz(max)
Triangle, Ramp 1MHz
Resolution
1μHz
Accuracy Stability
±20 ppm
Aging
±1 ppm, per 1 year
Tolerance
≤1μHz
Output
Characteristics(2)
Amplitude Range
1mVpp to 10 Vpp (into 50Ω)
2mVpp to 20 Vpp (open-circuit)
Accuracy
±2% of setting ±1 mVpp
(at 1 kHz/into 50Ω without DC
offset)
Resolution
0.1mV or 4 digits
Flatness
± 1% (0.1dB) ≦1MHz
± 3% (0.3dB) ≦50 MHz
± 16% (1.5dB) ≦60MHz(6)
(sinewave relative to 1 kHz/into
50Ω)
Units
Vpp, Vrms, dBm
Offset
Range
±5 Vpk ac +dc (into 50Ω)
±10Vpk ac +dc (Open circuit)
Accuracy
±(1% of setting + 5mV+ 0.5% of
amplitude)
Waveform
Output
Impedance
50Ω typical (fixed)
>10MΩ (output disabled)
Protection
Short-circuit protected
Overload relay automatically
disables main output
Ground Isolation
42Vpk max
Sync Output
Range
TTL-compatible into>1kΩ
Impedance
50Ω standard
Ground Isolation
42Vpk max
Sine wave
