MFG-2000 Quick Start Guide
22
Display
Parameter
Windows
The Parameter display and edit window.
Status Tabs
Displays the current channel and setting status.
Waveform
Display
Used to display the waveform
Soft Menu Keys
The function keys (F1~F6) under the LCD display
correspond directly to the soft menu keys.
