GW Instek MFG-2000 Series Quick Start Guide

QUICK REFERENCE
39
7. Press 1 + 0 + 0 + Hz
(F3).


z

8. Press MOD, FSK (F3),
Source (F1), INT (F1).

K 

9. Press the output key.
PM
Example: PM modulation. 800Hz sinusoidal carrier wave. 15 kHz
modulating sine wave. 180˚ phase deviation. Internal Source.
Output:

      
      
     
    
   
      
  

      

      
      
      
1. Press Waveform and
select Sine (F1).


2. Press the MOD key
and select PM (F4).


Input: N/A
3. Press the Freq/Rate
key, followed by 8 + 0
+ 0 + Hz (F4).

Q


z
4. Press the MOD key,
select PM (F4), Shape
(F4), Sine (F1).

 ha

5. Press MOD, then PM
(F4), PM Freq (F3).

 q
6. Press 1 + 5 + kHz
(F3).


kz
7. Press MOD, PM (F4),
PM Dev (F5).

K q
