SPS Power Supply User Manual
12
Course voltage
knob
Used for coarse adjustment of the
voltage output.
Positive output
terminal
Positive polarity terminal
Negative output
terminal
Negative polarity terminal
Ground terminal
Ground terminal
Current Display
Displays the current output
Voltage display
Displays the voltage output
Power switch
32:(5
Range selector
+,
$036
Selects high or low current range.
