GW Security GWSW1602G User Manual

1.4 Specification
Transmission distance is related with the cable, we suggest to use
standard Cat5e/6 network cable to get the best transmission result.
Products are subject to change without prior notice
3 4
Caution
2 Installation
2 1 Shipping List.
2.2 Installation Precautions
To avoid device damage or personal injury by improper use, please observe the
following precautions.
P
contact your local dealer.
lease check the following items before installation, if any missing, please
Item Name
Quantity
Unit
1
Device
1
Set
2
AC Power Line
1
Piece
4
Accessories
1
Set
3
User Manual
1
Piece
This is level A product, which may cause radio interference in living
environment. Users may need to take corresponding and effective
measures to solve the problem.
Anti counterfeiting label is attached to the injector's cover, so product
damage caused by unauthorized disassembly is not covered under
warranty.
-
2.2.1 Safety Precautions
Caution
Instruction
Item
Description
Product Type
Product Type
16ports
24ports
Port
Description
Downlink Ethernet Ports
16×RJ45,PoE+ 10/100Base- TX
24×RJ45,PoE+ 10/100Base- TX
Uplink Ethernet Ports
2* 10/ 100/1000Base- T+1* 1000Base- X(combo)
Power Input
1×AC Female Terminal
Grounding Terminal
1×Grounding Terminal
PoE&Power
Power Input
Mains on load,100～240VAC 50/ 60Hz
PoE Power Supply
End-span(1/2，3/ 6),IEEE802. 3 af/ at
PoE Max. Power Output
250W
370W(340W if 110V AC input)
Single Port Power Output&
Voltage
Single Port PoE Power Output≤30W, Voltage 54VDC
PoE Web
Management
PoE Management
Via Web( Default IP Address 192. 168.1. 200) to check, on/off and
adjust each port PoE output
Reset Button
PoE Web Reset
Long-press 3s, all Link LED solid on about 10s, switch reset to factory
default; short-press to restart.
One-key CCTV
CCTV Mode
1. Downlink ports only communicate with uplink ports;
2. Restrain network storm under 2Mbps
Network
Parameters
Network Standard
IEEE 802. 3,IEEE 802.3u,IEEE 802.3 ab
Transmission Distance
100m(Max.)
Exchange Capacity
.7 2Gbps
8. 8Gbps
Packet Transfer Rate
6. 55Mpps
5. 36Mpps
MAC Address
4K
Packet Data Cache
2. 75Mb
Indicators
Status
Power Input
1x Red LED
Downlink Ethernet Ports
Link:16x Green LED
PoE:16x Yellow LED
Link:24x Green LED
PoE: 24x Yellow LED
Uplink Ethernet Port Link
2x Green LED
PoE Power Output Percent
10x LED(Including 7x Green, 2x Yellow, 1x Red), separately indicate
10%、20%～100%
Protection
Level
ESD
/ - -6KV 8KV, Per:IEC61000 4 2
Surge Protection
6KV, Per: IEC61000- 4-5
Operation
Environment
Operation Temperature
- ℃～ ℃10 45
Storage Temperature
- ℃40 85℃ ～
Humidity( Non-condensing)
0～95%
Mechanics
Dimensions( LxWxH)
442 *207 *44.5mm mm mm
Material
Iron
Color
Black

GW Security GWSW1602G Specifications

General

Brand	GW Security
Model	GWSW1602G
Category	Switch
Language	English
